SWAM 2.0

746378Q3
Colour
Bronze
Colour Temperature

Availability Check
Availability
Drawing
Drawing

General

Scope
Exterior
Mounting
Wall
Fixation
Surface
Product colour
Bronze
Type
LED
IP Rating
IP65

LED

Light Colour
2700 K
LED lifetime
L80 / 70000 h

Optical

UGR
UGR < 16

Technical Details

Control
phase-cut dim
Voltage
220 - 240 V
Light flux
520 lm
Direct flux
300 lm
Indirect flux
220 lm
Total power
12.9 W
Safety class
Class 1

Physical

Height
110 mm
Diameter
185 mm
Weight
0.91 kg

Replaceability

Wall surface luminaire made from die-cast aluminium; surface Bronze; powder coated; matt texture; up and down light emission; PCB 3-step binning; phase-cut dim; light colour 2700 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 90; 220 - 240 V; degree of protection IP65; Class 1; light source replaceable by Wever & Ducré or by a professional with explicit authorization;
General: Wall, Surface, Bronze, IP65, Exterior, indirect 220 lm, direct 300 lm, total 520 lm, CIE flux code: 53 89 100 58 100
LED: 2700 K, CRI ≥ 90, L80 / 70000 h, initial MacAdam ≤ 3 SDCM
Optical: UGR < 16, ≥65° <3000 cd/m²
Electrical: phase-cut dim, 220 - 240 V, system 12.9 W, Class 1
Physical: diameter 185 mm, height 110 mm, 0.91 kg
