7094A1A5
Colour
Anthracite Grey
Colour Temperature
List price
117,40 €
incl 20% VAT

Complete article with driver from accessory section
Optional recessed housing incl. plasterkit, concrete housing available

Availability Check
Availability
Drawing
ORIS OUTDOOR 0.8
Drawing

General

Scope
Exterior
Mounting
Wall
Fixation
Recessed
Product colour
Anthracite Grey
RAL colour code
RAL 7016
Type
LED
IP Rating
IP65

LED

Light Colour
3000 K
LED lifetime
L70 / 60000h

Optical

Beam angle
Asymetric

Technical Details

Control
excl. driver
Voltage
6 V
Converter current
350 mA, 700 mA
Luminous flux
44 lm, 75 lm
LED inset power
2 W, 4.3 W
Safety class
Class 3

Physical

Height
80 mm
Length
80 mm
Width
33 mm
Weight
0.16 kg

Cutout

Length
66 mm
Width
66 mm
Min. ceiling thickness
12 mm
Recessed Depth
40 mm

Replaceability

Rectangular wall recessed luminaire made from aluminium; surface Anthracite Grey; powder coated; matt texture; RAL 7016; recessed depth 40 mm; suitable for ceiling thickness of min. 12 mm; PCB 3-step binning; light colour 3000 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 90; degree of protection IP65; Class 3; driver not included; light source not replaceable;
General: Wall, Recessed, Anthracite Grey, RAL 7016, IP65, Exterior, 44 | 75 lm, CIE flux code: 41 77 91 85 100
LED: 3000 K, CRI ≥ 90, L70 / 60000h, initial MacAdam ≤ 3 SDCM
Optical: Asymetric
Electrical: excl. driver, 6 V, inset 2.0 | 4.3 W, Class 3, 350 | 700 mA
Physical: length 80 mm, width 33 mm, height 80 mm, 0.16 kg
Cutout: length 66 mm, width 66 mm, min. ceiling thickness 12 mm, recessed depth 40 mm
