MAP ASYM 1.6

7516A8I5
Colour
Inox
Colour Temperature

Optional recessed housing available


Availability Check
Availability

General

Scope
Exterior
Mounting
Floor
Fixation
Recessed
Product colour
Inox
Type
LED
IP Rating
IP67
Shock resistance rating
IK09

LED

Light Colour
3000 K
LED lifetime
L70 / 55000h

Optical

Beam angle
Asymetric

Technical Details

Control
phase-cut dim
Voltage
220 - 240 V
Luminous flux
845 lm
Total power
15.7 W
Safety class
Class 2

Physical

Height
139 mm
Diameter
160 mm
Weight
1.72 kg

Cutout

Recessed Depth
185 mm

Replaceability

Round floor recessed luminaire made from stainless steel and glass; asymmetric light beam; surface Inox; recessed depth 185 mm; with COB (Chip on Board) technology for maximum efficiency; phase-cut dim; light colour 3000 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 90; degree of protection IP67; Class 2; driver not included; light source replaceable by Wever & Ducré or by a professional with explicit authorization;
General: Floor, Recessed, Inox, IP67, IK09, Exterior, 845 lm, CIE flux code: 38 67 87 0 100
LED: 3000 K, CRI ≥ 90, L70 / 55000h, initial MacAdam ≤ 3 SDCM
Optical: Asymetric
Electrical: phase-cut dim, 220 - 240 V, system 15.7 W, Class 2
Physical: diameter 160 mm, height 139 mm, 1.72 kg
Cutout: recessed depth 185 mm
