DEEP ADJUST 2.0 PAR16
DEEP ADJUST 2.0 PAR16
DEEP ADJUST 2.0 LED
DEEP ADJUST 2.0 LED
DEEP ADJUST 2.0 Loxone
DEEP ADJUST 2.0 Loxone

DEEP ADJUST 2.0 Loxone

18476LB9
Electronic
Colour
Black Matt
Colour Temperature
Beam Angle
List price
243,10 €
incl 20% VAT

Article includes all needed accessories

Availability Check
Availability
Drawing
DEEP ADJUST 2.0 Loxone
Drawing

General

Scope
Interior
Mounting
Ceiling
Fixation
Recessed
Product colour
Black Matt
Type
Loxone
IP Rating
IP20

LED

Light Colour
colour warm dimming
Colour Temperature Range
1800 K - 3000 K
Colour Rendering Index
CRI ≥ 90

Optical

Beam angle
38° Standard

Technical Details

Control
excl. power supply
Voltage
24 V
Luminous flux
800 lm
Safety class
Class 3

Physical

Height
85 mm
Length
182 mm
Width
94 mm
Weight
0.61 kg
Tilt max.
35°
Rotation
355°

Cutout

Cut-out dimensions
86-89x172-178
Min. ceiling thickness
4 mm
Max. ceiling thickness
23 mm
Recessed Depth
90 mm

Replaceability

Oval ceiling recessed downlight made from die-cast aluminium; adjustable; surface Black Matt; powder coated, matt texture; recessed depth 90 mm; with COB (Chip on Board) technology for maximum efficiency; light colour 1800 K - 3000 K colour warm dimming; CRI ≥ 90; beam angle 38°; 355° rotatable and 35° tiltable; degree of protection IP20; Class 3; IC rated; driver included; light source replaceable by Wever & Ducré or by a professional with explicit authorization;
General: Ceiling, Recessed, tilt max 35°, rotation 355°, Black Matt, IP20, Interior, 800 lm
LED: colour warm dimming, 1800 K - 3000 K, CRI ≥ 90, L80 / 100000h, initial MacAdam ≤ 2 SDCM
Optical: Standard, beam angle 38°
Electrical: excl. power supply, 24 V, system 7.0 W, Class 3
Physical: length 182 mm, width 94 mm, height 85 mm, 0.61 kg
Cutout: min. ceiling thickness 4 mm, max. ceiling thickness 23 mm, recessed depth 90 mm, 86-89x172-178
