Visualisation
Example picture
CLEA 3.0
General
Scope
Interior
Mounting
Ceiling
Fixation
Surface
Product colour
Feel Jade
RAL colour code
NCS S 2005 – G90Y
Type
LED
IP Rating
IP20
LED
Light Colour
2700 K
LED lifetime
L80 / 50000 h
Optical
Beam angle
Opal
Technical Details
Control
phase-cut dim
Voltage
220 - 240 V
Luminous flux
615 lm
Total power
14.1 W
Safety class
Class 1
Physical
Height
96 mm
Diameter
350 mm
Weight
0.78 kg
Additional Information
Notice
White opal glass hand blown
Replaceability
Awards
Round shape ceiling surface mounted luminaire with diffuse light; aluminium base in White Matt wet painted; matt texture; aluminium shade; surface Feel Jade wet painted; matt texture; NCS S 2005 – G90Y; white opal glass handblown; with COB (Chip on Board) technology for maximum efficiency; phase-cut dim; light colour 2700 K; binning initial MacAdam ≤ 2 SDCM; CRI ≥ 90; CRI (Colour Rendering Index) ≥ 90; degree of protection IP20; Class 1; driver included; light source replaceable by Wever & Ducré or by a professional with explicit authorization; control gear replaceable by end-user;
General:
Ceiling, Surface, Feel Jade, NCS S 2005 – G90Y, IP20, Interior, 615 lm, CIE flux code: 42 76 95 99 100
LED:
2700 K, CRI ≥ 90, L80 / 50000 h, initial MacAdam ≤ 2 SDCM
Optical:
Opal
Electrical:
phase-cut dim, 220 - 240 V, system 14.1 W, Class 1
Physical:
diameter 350 mm, height 96 mm, 0.78 kg
