MIRBI long 1.0
MIRBI long 1.0
MIRBI long 1.0
MIRBI long 1.0

MIRBI long 1.0

329188W5
Colour
White Matt + Clear/Opal PMMA
Colour Temperature
Availability Check
Availability
Drawing
MIRBI long 1.0
Drawing

General

Scope
Interior
Mounting
Wall
Fixation
Surface
Product colour
White Matt + Clear/Opal PMMA
RAL colour code
RAL 9003
Type
LED
IP Rating
IP44

LED

Light Colour
3000 K

Technical Details

Control
incl. output selector | phase-cut dim
Voltage
220 - 240 V
Luminous flux
280 lm, 460 lm
Total power
5 W, 7 W
Safety class
Class 1

Physical

Height
42 mm
Length
300 mm
Width
40 mm
Weight
0.72 kg

Replaceability

Wall surface luminaire made from aluminium; surface White Matt; powder coated; matt texture; opal PMMA; RAL 9003; PCB 3-step binning; light colour 3000 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 90; inclusive output selector (choose between low and high luminosity); degree of protection IP44; Class 1; light source not replaceable;
General: Wall, Surface, White Matt + Clear/Opal PMMA, RAL 9003, IP44, Interior, 280 | 460 lm, CIE flux code: 49 77 94 94 100
LED: 3000 K, CRI ≥ 90, L80 / 60000h, initial MacAdam ≤ 3 SDCM
Optical: Opal
Electrical: incl. output selector | phase-cut dim, 220 - 240 V, system 5.0 | 7.0 W, Class 1
Physical: length 300 mm, width 40 mm, height 42 mm, 0.72 kg
